HDMI Socket HDMI Female Connector Plug-in HDMI Interface – GSC-USA-0122

HDMI Socket HDMI Female Connector Plug-in HDMI Interface – GSC-USA-0122

USBSMT
Tags:
#PCB#Receptacle#SMT#USB Connector#USB Type-A
Share:LinkedInFacebookXWhatsAppEmail

GSC-USA-0122 is a USB connector, 11.2×7.5×3.20 mm, gold-plated, front-insertion, rear-mount (surface-mount type) HDMI connector. GSCONN part GSC-USA-0122.

Request a Quote → Download Datasheet
Surface MountSMT termination
5,000 CyclesRated mating life

Technical Specifications

SeriesHDMI JACK
TypeHDMI connector / Gold-plated copper housing
Mating cycles5,000 cycles
Insertion / Removal force4.5 kg MAX

Key Features

  • 11.2×7.5×3.20 mm
  • gold-plated
  • front-insertion
  • rear-mount (surface-mount type) HDMI connector

Applications

  • Consumer electronics
  • USB peripherals and hubs
  • Charging devices
  • Industrial control equipment
Drawing & Dimensions
HDMI Socket HDMI Female Connector Plug-in HDMI Interface – GSC-USA-0122 drawing

GSC-USA-0122 is a USB connector, 11.2×7.5×3.20 mm, gold-plated, front-insertion, rear-mount (surface-mount type) HDMI connector.

Series HDMI JACK
Type HDMI connector / Gold-plated copper housing
Mating cycles 5,000 cycles
Insertion / Removal force 4.5 kg MAX

Downloads

Technical DrawingPDF · 84 KB
