21pin CF CARD SLOT EXPRESS HOST PUSH-PUSH CONNECTOR SMT – GSC-SDC-0013
21 PinWaterproofSMT
21pin CF CARD SLOT EXPRESS HOST PUSH-PUSH CONNECTOR SMT, Hi-Temp Temperature, UL94V-0, Black housing, Copper Alloy contacts, -25°C to +85°C. GSCONN part GSC-SDC-0013.
Technical Specifications
| Type | Push-push |
| Dimensions | L32.30xW29.75xH4.75mm |
| Housing | Hi-Temp Temperature, UL94V-0, Black |
| Terminal | Copper Alloy |
| Shell | Stainless steel |
| Mating Cycles | 10000 Insertions |
| Temperature | -25°C to +85°C |
| Current Rating | 0.5 AMP |
| Insulation Resistance | 500MΩ Min. |
| Contact Resistance | 100mΩ Max. |
| Dielectric Voltage | 500V AC/Minute |
Key Features
- Push-push card insertion
- Dimensions L32.30xW29.75xH4.75mm
- Hi-Temp Temperature, UL94V-0, Black
- Copper Alloy contact system
- Stainless steel shell
- Rated 0.5 AMP
- 500V AC/Minute dielectric withstanding voltage
- Contact resistance 100mΩ Max.
Applications
- Consumer electronics
- Industrial data loggers
- Dash cams and surveillance
- POS terminals
Drawing & Dimensions
GSC-SDC-0013 is a Push-push connector. The housing is Hi-Temp Temperature, UL94V-0, Black; the contact system is Copper Alloy; the shell is Stainless steel. Electrically it is rated 0.5 AMP, with a withstanding voltage of 500V AC/Minute, over an operating temperature range of -25°C to +85°C. Mechanically it offers mating durability of 10000 Insertions, insulation resistance 500MΩ Min., contact resistance 100mΩ Max. Typical applications include Consumer electronics, Industrial data loggers, Dash cams and surveillance, and POS terminals.
| Type | Push-push |
| Dimensions | L32.30xW29.75xH4.75mm |
| Housing | Hi-Temp Temperature, UL94V-0, Black |
| Terminal | Copper Alloy |
| Shell | Stainless steel |
| Mating Cycles | 10000 Insertions |
| Temperature | -25°C to +85°C |
| Current Rating | 0.5 AMP |
| Insulation Resistance | 500MΩ Min. |
| Contact Resistance | 100mΩ Max. |
| Dielectric Voltage | 500V AC/Minute |
