Audio Jack 3.6mm Headphone Jack – GSC-AUD-0104
Audio5 PinSMT
GSC-AUD-0104 is an audio connector, 3.6 mm, 5-pin, with positioning posts, flat-bottom (surface-mount type) audio jack. GSCONN part GSC-AUD-0104.
Surface MountSMT termination
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×14×6×4.7mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- with positioning posts
- flat‑bottom (surface‑mount type) audio jack
- Dimensions: ￠3.6×14×6×4.7mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0104 is an audio connector, 3.6 mm, 5-pin, with positioning posts, flat-bottom (surface-mount type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×14×6×4.7mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
