Audio Jack angled headphone jack – GSC-AUD-0028
Audio6 PinRight Angle
GSC-AUD-0028 is an audio 6-contact connector, ￠3.6mm 6P angled, flush-mount (board-mounted) audio jack. GSCONN part GSC-AUD-0028.
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×12.6×6.7×4.75mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm 6P angled
- flush-mount (board-mounted) audio jack
- Dimensions: ￠3.6×12.6×6.7×4.75mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0028 is an audio 6-contact connector, ￠3.6mm 6P angled, flush-mount (board-mounted) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×12.6×6.7×4.75mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
