Audio Jack Plug-in Headphone Jack – GSC-AUD-0033
Audio5 PinThrough-Hole
GSC-AUD-0033 is an audio connector, 3.6 mm, 5-pin audio jack with positioning posts (board-mounted type). GSCONN part GSC-AUD-0033.
Through-HolePCB solder termination
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×15×12mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- 5-pin audio jack with positioning posts (board-mounted type)
- Dimensions: ￠3.6×15×12mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0033 is an audio connector, 3.6 mm, 5-pin audio jack with positioning posts (board-mounted type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×15×12mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
