DC socket DC Jack DC power socket – GSC-DCJ-0005
DC power2 PinThrough-HoleRight Angle
GSC-DCJ-0005 is a DC power 2-contact connector, horizontal 2P ￠1.3mm (board-mount type) DC socket. GSCONN part GSC-DCJ-0005.
Through-HolePCB solder termination
5,000 CyclesRated mating life
2 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Plugin-based / 2P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Horizontal 2P ￠1.3mm (board-mount type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0005 is a DC power 2-contact connector, horizontal 2P ￠1.3mm (board-mount type) DC socket.
| Series | DC JACK |
|---|---|
| Type | Plugin-based / 2P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
