DC socket DC Jack DC power socket – GSC-DCJ-0009
DC power9 PinThrough-Hole
GSC-DCJ-0009 is a DC power 9-contact connector, through-hole 9P, 4.7 mm pitch (board-mounted plug-in type) DC socket. GSCONN part GSC-DCJ-0009.
Through-HolePCB solder termination
5,000 CyclesRated mating life
9 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Flush-mounted / 9P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
Key Features
- Through-hole 9P
- 4.7 mm pitch (board-mounted plug-in type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0009 is a DC power 9-contact connector, through-hole 9P, 4.7 mm pitch (board-mounted plug-in type) DC socket.
| Series | DC JACK |
|---|---|
| Type | Flush-mounted / 9P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
