DC Socket DC Jack DC Power Socket – GSC-DCJ-0046
DC power3 PinThrough-Hole
GSC-DCJ-0046 is a DC power 3-contact connector, 3P ￠1.65mm DC socket with card slot (board-mounted plug-in type). GSCONN part GSC-DCJ-0046.
Through-HolePCB solder termination
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | With card slot / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3P ￠1.65mm DC socket with card slot (board-mounted plug-in type)
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0046 is a DC power 3-contact connector, 3P ￠1.65mm DC socket with card slot (board-mounted plug-in type).
| Series | DC JACK |
|---|---|
| Type | With card slot / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
