DC Socket DC Jack DC Power Socket – GSC-DCJ-0079
DC power3 Pin
GSC-DCJ-0079 is a DC power 3-contact connector, 3P DC socket with screw holes, ￠2.0 & 2.35 & 2.5 mm (solder-type). GSCONN part GSC-DCJ-0079.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | With screw holes / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3P DC socket with screw holes
- ￠2.0 & 2.35 & 2.5 mm (solder‑type)
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0079 is a DC power 3-contact connector, 3P DC socket with screw holes, ￠2.0 & 2.35 & 2.5 mm (solder-type).
| Series | DC JACK |
|---|---|
| Type | With screw holes / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
