DC Socket DC Jack DC Power Socket – GSC-DCJ-0084
DC power3 PinThrough-Hole
GSC-DCJ-0084 is a DC power 3-contact connector, dC socket with card slot, 3P, ￠2.0 & 2.35 & 2.5 mm (board-mounted plug-in type). GSCONN part GSC-DCJ-0084.
Through-HolePCB solder termination
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Plugin-based / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- DC socket with card slot
- ￠2.0 & 2.35 & 2.5 mm (board-mounted plug-in type)
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0084 is a DC power 3-contact connector, dC socket with card slot, 3P, ￠2.0 & 2.35 & 2.5 mm (board-mounted plug-in type).
| Series | DC JACK |
|---|---|
| Type | Plugin-based / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
