DC Socket DC Jack DC Power Socket – GSC-DCJ-0091
DC power3 PinThrough-HoleRight Angle
GSC-DCJ-0091 is a DC power 3-contact connector, horizontal 3P ￠0.65mm (board-mounted plug-in) DC socket. GSCONN part GSC-DCJ-0091.
Through-HolePCB solder termination
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Plugin-based / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Horizontal 3P ￠0.65mm (board-mounted plug-in) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0091 is a DC power 3-contact connector, horizontal 3P ￠0.65mm (board-mounted plug-in) DC socket.
| Series | DC JACK |
|---|---|
| Type | Plugin-based / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
