DC Socket DC Jack DC Power Socket – GSC-DCJ-0098
DC power3 PinThrough-HoleRight Angle
GSC-DCJ-0098 is a DC power 3-contact connector, horizontal 3P, ￠2.0 & 2.5 mm, with locking groove (board-mounted plug-in type) DC socket. GSCONN part GSC-DCJ-0098.
Through-HolePCB solder termination
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | With card slot / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Horizontal 3P
- ￠2.0 & 2.5 mm
- with locking groove (board-mounted plug-in type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0098 is a DC power 3-contact connector, horizontal 3P, ￠2.0 & 2.5 mm, with locking groove (board-mounted plug-in type) DC socket.
| Series | DC JACK |
|---|---|
| Type | With card slot / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
