DC Socket DC Jack DC Power Socket – GSC-DCJ-0102
DC power3 PinRight Angle
GSC-DCJ-0102 is a DC power 3-contact connector, horizontal 3P ￠1.0 & 1.3 & 1.45 mm (board-mount type) DC socket. GSCONN part GSC-DCJ-0102.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Flat-mouth / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Horizontal 3P ￠1.0 & 1.3 & 1.45 mm (board-mount type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0102 is a DC power 3-contact connector, horizontal 3P ￠1.0 & 1.3 & 1.45 mm (board-mount type) DC socket.
| Series | DC JACK |
|---|---|
| Type | Flat-mouth / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
