DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0012
DC power3 PinSMT
GSC-DCJ-0012 is a DC power 3-contact connector, high-current-rated 3P, Ø2.0 & 2.5 mm (surface-mount type) DC socket. GSCONN part GSC-DCJ-0012.
Surface MountSMT termination
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | High-current resistant / 3P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
Key Features
- High-current‑rated 3P
- Ø2.0 & 2.5 mm (surface-mount type) DC socket
- Insertion / Removal life 5,000 cycles
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0012 is a DC power 3-contact connector, high-current-rated 3P, Ø2.0 & 2.5 mm (surface-mount type) DC socket.
| Series | DC JACK |
|---|---|
| Type | High-current resistant / 3P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
