DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0052

DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0052

DC power5 PinThrough-HoleRight Angle
Tags:
#5 Pin#DC Jack#DIP#PCB#Right Angle
Share:LinkedInFacebookXWhatsAppEmail

GSC-DCJ-0052 is a DC power 5-contact connector, horizontal 5P, ￠2.0 & 2.5 mm, high-current (board-mounted plug-in) DC socket. GSCONN part GSC-DCJ-0052.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
5,000 CyclesRated mating life
5 PinContact count

Technical Specifications

SeriesDC JACK
TypeHigh Current / 5P
Mating cycles5,000 cycles
Insertion / Removal force3–20 N

Key Features

  • Horizontal 5P
  • ￠2.0 & 2.5 mm
  • high-current (board-mounted plug-in) DC socket

Applications

  • Power adapters and chargers
  • Set-top boxes
  • Routers and network equipment
  • Industrial control equipment
Drawing & Dimensions
DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0052 drawing

GSC-DCJ-0052 is a DC power 5-contact connector, horizontal 5P, ￠2.0 & 2.5 mm, high-current (board-mounted plug-in) DC socket.

Series DC JACK
Type High Current / 5P
Mating cycles 5,000 cycles
Insertion / Removal force 3–20 N

Downloads

Technical DrawingPDF · 38 KB
