DC Socket DC Jack High-Current DC Power Socket – GSC-DCJ-0115
DC power3 PinRight Angle
GSC-DCJ-0115 is a DC power 3-contact connector, horizontal 3P connector, 2.0 mm pitch (board-mounted type), DC socket. GSCONN part GSC-DCJ-0115.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Bag opening / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- Horizontal 3P connector
- 2.0 mm pitch (board-mounted type)
- DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0115 is a DC power 3-contact connector, horizontal 3P connector, 2.0 mm pitch (board-mounted type), DC socket.
| Series | DC JACK |
|---|---|
| Type | Bag opening / 3P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
