DC Socket DC Jack High-Current Power Socket – GSC-DCJ-0055
DC power5 PinThrough-Hole
GSC-DCJ-0055 is a DC power 5-contact connector, high-current 5P, Ø2.0 & 2.5 mm (board-mounted plug-in type) DC socket. GSCONN part GSC-DCJ-0055.
Through-HolePCB solder termination
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | High Current / 5P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- High-current 5P
- Ø2.0 & 2.5 mm (board-mounted plug-in type) DC socket
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0055 is a DC power 5-contact connector, high-current 5P, Ø2.0 & 2.5 mm (board-mounted plug-in type) DC socket.
| Series | DC JACK |
|---|---|
| Type | High Current / 5P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
