DC Socket DC Jack Through-Panel DC Power Socket – GSC-DCJ-0011
DC power5 PinThrough-Hole
GSC-DCJ-0011 is a DC power 5-contact connector, through-hole 5P, ￠1.3 mm (board-mounted plug-in type) DC socket. GSCONN part GSC-DCJ-0011.
Through-HolePCB solder termination
5 PinContact count
Technical Specifications
| Series | DC JACK |
| Type | Flush-mounted / 5P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
Key Features
- Through-hole 5P
- ￠1.3 mm (board-mounted plug-in type) DC socket
- Insertion / Removal life 5,000 cycles
Applications
- Power adapters and chargers
- Set-top boxes
- Routers and network equipment
- Industrial control equipment
Drawing & Dimensions
GSC-DCJ-0011 is a DC power 5-contact connector, through-hole 5P, ￠1.3 mm (board-mounted plug-in type) DC socket.
| Series | DC JACK |
|---|---|
| Type | Flush-mounted / 5P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
