HDMI Socket HDMI Female Connector Vertical SMD HDMI Interface – GSC-USA-0069
USBSMT
GSC-USA-0069 is a USB connector, sinking-board type, H=3.75 mm, with fixed terminals (surface-mount), HDMI connector. GSCONN part GSC-USA-0069.
Surface MountSMT termination
5,000 CyclesRated mating life
Technical Specifications
| Series | HDMI JACK |
| Type | Recessed plate type, H=3.75mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 4.5 kgf MAX |
Key Features
- Sinking‑board type
- H=3.75 mm
- with fixed terminals (surface‑mount)
- HDMI connector
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0069 is a USB connector, sinking-board type, H=3.75 mm, with fixed terminals (surface-mount), HDMI connector.
| Series | HDMI JACK |
|---|---|
| Type | Recessed plate type, H=3.75mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 4.5 kgf MAX |
