Headphone Jack angled audio jack – GSC-AUD-0011
Audio5 PinRight Angle
GSC-AUD-0011 is an audio 5-contact connector, 3.6mm 5P angled (board-mount type) audio jack. GSCONN part GSC-AUD-0011.
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6 / Beveled end |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6mm 5P angled (board-mount type) audio jack
- Dimensions: ￠3.6 / Beveled end
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0011 is an audio 5-contact connector, 3.6mm 5P angled (board-mount type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6 / Beveled end |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
