Headphone Jack angled audio jack – GSC-AUD-0026
Audio6 PinThrough-Hole
GSC-AUD-0026 is an audio 6-contact connector, ￠3.6mm 6P flush-mount 2.75mm (board-mounted plug-in type) audio jack. GSCONN part GSC-AUD-0026.
Through-HolePCB solder termination
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm 6P flush-mount 2.75mm (board-mounted plug-in type) audio jack
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0026 is an audio 6-contact connector, ￠3.6mm 6P flush-mount 2.75mm (board-mounted plug-in type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
