Headphone Jack angled audio jack – GSC-AUD-0029
Audio6 PinRight Angle
GSC-AUD-0029 is an audio 6-contact connector, ￠3.6mm 6P right-angle flush-mount (board-mounted) audio jack. GSCONN part GSC-AUD-0029.
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×12.5×6.3×4.6mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
Key Features
- ￠3.6mm 6P right-angle flush-mount (board-mounted) audio jack
- Dimensions: ￠3.6×12.5×6.3×4.6mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0029 is an audio 6-contact connector, ￠3.6mm 6P right-angle flush-mount (board-mounted) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×12.5×6.3×4.6mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
