Headphone Jack Audio Jack 3.5mm Female Headphone Socket – GSC-AUD-0039
Audio4 PinThrough-Hole
GSC-AUD-0039 is an audio 4-contact connector, 3.6 mm, 4P, with positioning posts (board-mounted plug-in type) audio jack. GSCONN part GSC-AUD-0039.
Through-HolePCB solder termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×14×6.3mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- with positioning posts (board-mounted plug-in type) audio jack
- Dimensions: ￠3.6×14×6.3mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0039 is an audio 4-contact connector, 3.6 mm, 4P, with positioning posts (board-mounted plug-in type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×14×6.3mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
