Headphone Jack Audio Jack with Nut – GSC-AUD-0041
Audio3 Pin
GSC-AUD-0041 is an audio 3-contact connector, 3.6mm 3P audio jack with nut (board-mounted type). GSCONN part GSC-AUD-0041.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | Ø3.6×16.3×9.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6mm 3P audio jack with nut (board-mounted type)
- Dimensions: Ø3.6×16.3×9.2mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0041 is an audio 3-contact connector, 3.6mm 3P audio jack with nut (board-mounted type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | Ø3.6×16.3×9.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
