Headphone Jack Audio Jack with Nut – GSC-AUD-0054
AudioThrough-Hole
GSC-AUD-0054 is an audio connector, ￠3.6mm metal-head and threaded-head options available (board-mount plug-in type) audio jack. GSCONN part GSC-AUD-0054.
Through-HolePCB solder termination
5,000 CyclesRated mating life
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | Ø3.6×17.7×11.5mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm metal‑head and threaded‑head options available (board‑mount plug‑in type) audio jack
- Dimensions: Ø3.6×17.7×11.5mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0054 is an audio connector, ￠3.6mm metal-head and threaded-head options available (board-mount plug-in type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | Ø3.6×17.7×11.5mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
