Headphone Jack Audio Jack with Posts – GSC-AUD-0016
Audio5 PinSMT
GSC-AUD-0016 is an audio connector, 3.6 mm, 5-pin, with posts, gold-plated (surface-mount type) audio jack. GSCONN part GSC-AUD-0016.
Surface MountSMT termination
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×14×7.4×6.1mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
Key Features
- 3.6 mm
- with posts
- gold-plated (surface-mount type) audio jack
- Dimensions: ￠3.6×14×7.4×6.1mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0016 is an audio connector, 3.6 mm, 5-pin, with posts, gold-plated (surface-mount type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×14×7.4×6.1mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 2.94–29.4 N |
