Headphone Jack Audio Jack with Switch – GSC-AUD-0089
Audio7 PinSMT
GSC-AUD-0089 is an audio connector, 3.6 mm, 7-pin audio jack with positioning posts (surface-mount type). GSCONN part GSC-AUD-0089.
Surface MountSMT termination
5,000 CyclesRated mating life
7 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠2.6×14.5×6×5.0mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- 7-pin audio jack with positioning posts (surface-mount type)
- Dimensions: ￠2.6×14.5×6×5.0mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0089 is an audio connector, 3.6 mm, 7-pin audio jack with positioning posts (surface-mount type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠2.6×14.5×6×5.0mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
