Headphone Jack Cylindrical Audio Jack – GSC-AUD-0035
Audio
GSC-AUD-0035 is an audio connector, ￠3.6mm cylindrical audio jack with nut (board-mounted type). GSCONN part GSC-AUD-0035.
5,000 CyclesRated mating life
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×16.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm cylindrical audio jack with nut (board-mounted type)
- Dimensions: ￠3.6×16.2mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0035 is an audio connector, ￠3.6mm cylindrical audio jack with nut (board-mounted type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×16.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
