GSC-AUD-0013 is an audio connector, 4.5mm, 5-pole gold-plated (female) audio jack. GSCONN part GSC-AUD-0013.

Request a Quote → Download Datasheet
5,000 CyclesRated mating life

Technical Specifications

SeriesAUDIO JACK
Dimensions￠4.5 / Five-pole
Mating cycles5,000 cycles
Insertion / Removal force3–20 N

Key Features

  • 5‑pole gold‑plated (female) audio jack
  • Dimensions: ￠4.5 / Five-pole

Applications

  • Headphones and earphones
  • Portable audio players
  • Set-top boxes and TVs
  • Mobile devices
Drawing & Dimensions
Headphone Jack Five-Pole Audio Jack – GSC-AUD-0013 drawing

GSC-AUD-0013 is an audio connector, 4.5mm, 5-pole gold-plated (female) audio jack.

Series AUDIO JACK
Dimensions ￠4.5 / Five-pole
Mating cycles 5,000 cycles
Insertion / Removal force 3–20 N

Downloads

Technical DrawingPDF · 45 KB
