Headphone Jack Five-Pole Audio Jack – GSC-AUD-0017
Audio6 PinSMT
GSC-AUD-0017 is an audio 6-contact connector, 3.6 mm, 6P gold-plated, five-pole (surface-mount) audio jack. GSCONN part GSC-AUD-0017.
Surface MountSMT termination
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- 6P gold-plated
- five-pole (surface-mount) audio jack
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0017 is an audio 6-contact connector, 3.6 mm, 6P gold-plated, five-pole (surface-mount) audio jack.
| Series | AUDIO JACK |
|---|---|
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
