Headphone Jack – GSC-AUD-0061
Audio11 PinThrough-Hole
GSC-AUD-0061 is an audio connector, 3.6 mm, 11-pin audio jack with positioning posts (board-mounted plug-in type). GSCONN part GSC-AUD-0061.
Through-HolePCB solder termination
5,000 CyclesRated mating life
11 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠2.6×21×12×10mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- 11-pin audio jack with positioning posts (board-mounted plug-in type)
- Dimensions: ￠2.6×21×12×10mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0061 is an audio connector, 3.6 mm, 11-pin audio jack with positioning posts (board-mounted plug-in type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠2.6×21×12×10mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
