Headphone Jack – GSC-AUD-0080
Audio5 Pin
GSC-AUD-0080 is an audio 5-contact connector, ￠2.6mm 5P audio jack with positioning posts (board-mounted type). GSCONN part GSC-AUD-0080.
5,000 CyclesRated mating life
5 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠2.6×12×9×4.1mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠2.6mm 5P audio jack with positioning posts (board-mounted type)
- Dimensions: ￠2.6×12×9×4.1mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0080 is an audio 5-contact connector, ￠2.6mm 5P audio jack with positioning posts (board-mounted type).
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠2.6×12×9×4.1mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
