Headphone Jack – GSC-AUD-0082
Audio6 PinSMT
GSC-AUD-0082 is an audio 6-contact connector, ￠3.6mm 6P recessed board 2.8mm (surface-mount type) audio jack. GSCONN part GSC-AUD-0082.
Surface MountSMT termination
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO SWITCH |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm 6P recessed board 2.8mm (surface-mount type) audio jack
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0082 is an audio 6-contact connector, ￠3.6mm 6P recessed board 2.8mm (surface-mount type) audio jack.
| Series | AUDIO SWITCH |
|---|---|
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
