Headphone Jack – GSC-AUD-0095
Audio8 PinSMT
GSC-AUD-0095 is an audio 8-contact connector, 3.6 mm, 8P, with positioning posts (surface-mount type), audio jack. GSCONN part GSC-AUD-0095.
Surface MountSMT termination
5,000 CyclesRated mating life
8 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | Ø3.6 with locating pin |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- with positioning posts (surface-mount type)
- audio jack
- Dimensions: Ø3.6 with locating pin
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0095 is an audio 8-contact connector, 3.6 mm, 8P, with positioning posts (surface-mount type), audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | Ø3.6 with locating pin |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
