Headphone Jack – GSC-AUD-0114
Audio4 PinSMT
GSC-AUD-0114 is an audio 4-contact connector, 3.6 mm, 4P with positioning posts (surface-mount type) audio jack. GSCONN part GSC-AUD-0114.
Surface MountSMT termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×13.1×6.1×5mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6 mm
- 4P with positioning posts (surface-mount type) audio jack
- Dimensions: ￠3.6×13.1×6.1×5mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0114 is an audio 4-contact connector, 3.6 mm, 4P with positioning posts (surface-mount type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×13.1×6.1×5mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
