Headphone Jack – GSC-AUD-0123
Audio6 PinSMT
GSC-AUD-0123 is an audio 6-contact connector, ￠2.6mm 6P with positioning posts (surface-mount type) audio jack. GSCONN part GSC-AUD-0123.
Surface MountSMT termination
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠2.6×12×5×3.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
Key Features
- ￠2.6mm 6P with positioning posts (surface-mount type) audio jack
- Dimensions: ￠2.6×12×5×3.2mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0123 is an audio 6-contact connector, ￠2.6mm 6P with positioning posts (surface-mount type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠2.6×12×5×3.2mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
