Headphone Jack Metal-Contact Audio Jack – GSC-AUD-0055
Audio3 Pin
GSC-AUD-0055 is an audio 3-contact connector, ￠3.6mm 3P metal-head (solder-type) audio jack. GSCONN part GSC-AUD-0055.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | Ø3.6×18.5×7.8mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm 3P metal‑head (solder‑type) audio jack
- Dimensions: Ø3.6×18.5×7.8mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0055 is an audio 3-contact connector, ￠3.6mm 3P metal-head (solder-type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | Ø3.6×18.5×7.8mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
