Headphone Jack Soldered Wire Audio Jack – GSC-AUD-0071
Audio3 Pin
GSC-AUD-0071 is an audio 3-contact connector, 3.6mm 3P female connector with nut (solder-type) audio jack. GSCONN part GSC-AUD-0071.
5,000 CyclesRated mating life
3 PinContact count
Technical Specifications
| Series | AUDIO JACK |
| Dimensions | ￠3.6×13×9×10mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 3.6mm 3P female connector with nut (solder-type) audio jack
- Dimensions: ￠3.6×13×9×10mm
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0071 is an audio 3-contact connector, 3.6mm 3P female connector with nut (solder-type) audio jack.
| Series | AUDIO JACK |
|---|---|
| Dimensions | ￠3.6×13×9×10mm |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
