Headphone Jack Through-Panel Audio Jack – GSC-AUD-0087
AudioThrough-Hole
GSC-AUD-0087 is an audio connector, ￠3.6mm recessed panel, 1.9 & 3.0 mm (plug-in type on the panel), audio jack. GSCONN part GSC-AUD-0087.
Through-HolePCB solder termination
5,000 CyclesRated mating life
Technical Specifications
| Series | AUDIO JACK |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- ￠3.6mm recessed panel
- 1.9 & 3.0 mm (plug-in type on the panel)
- audio jack
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0087 is an audio connector, ￠3.6mm recessed panel, 1.9 & 3.0 mm (plug-in type on the panel), audio jack.
| Series | AUDIO JACK |
|---|---|
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–20 N |
