Headphone Jack Waterproof Audio Jack – GSC-AUD-0006
Audio6 PinThrough-HoleWaterproof
GSC-AUD-0006 is an audio 6-contact connector, 3.6 mm, 6P, waterproof (board-mount plug-in) audio jack. GSCONN part GSC-AUD-0006.
WaterproofRated waterproof construction
Through-HolePCB solder termination
5,000 CyclesRated mating life
Technical Specifications
| Series | AUDIO JACK |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
Key Features
- 3.6 mm
- waterproof (board-mount plug-in) audio jack
Applications
- Headphones and earphones
- Portable audio players
- Set-top boxes and TVs
- Mobile devices
Drawing & Dimensions
GSC-AUD-0006 is an audio 6-contact connector, 3.6 mm, 6P, waterproof (board-mount plug-in) audio jack.
| Series | AUDIO JACK |
|---|---|
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3–30 N |
