patch connector vertical connector – GSC-BAR-0002

patch connector vertical connector – GSC-BAR-0002

Wire-to-board2–20 PinSMTRight Angle
Tags:
#PCB#Right Angle#SMT#Vertical#Wire to Board Connector
Share:LinkedInFacebookXWhatsAppEmail

GSC-BAR-0002 is a wire-to-board connector, horizontal Height 3.6mm 2-20P Optional (Surface Mount) Connector. GSCONN part GSC-BAR-0002.

Request a Quote → Download Datasheet
Surface MountSMT termination

Technical Specifications

SeriesCONNECTOR
Number of contacts2-20P
TypeHorizontal/Patch
Height3.6mm

Key Features

  • Horizontal Height 3.6mm 2-20P Optional (Surface Mount) Connector

Applications

  • Consumer electronics
  • LED modules
  • Industrial control boards
  • Wire-to-board assemblies
Drawing & Dimensions
patch connector vertical connector – GSC-BAR-0002 drawing

GSC-BAR-0002 is a wire-to-board connector, horizontal Height 3.6mm 2-20P Optional (Surface Mount) Connector.

Series CONNECTOR
Number of contacts 2-20P
Type Horizontal/Patch
Height 3.6mm

Downloads

Technical DrawingPDF · 71 KB
