Stackable Type-C USB 3.1 Raised Single-Layer Connector – C071314

Name: USB 3.1 Single-Layer 90 Degree Type-C - C071314 | GSCONN
Brand: GSCONN

USB 3.110GbpsBoard-Mount

Tags:

#Raised #Single-Layer #Stackable #USB 3.1 #USB Connector #USB Type-C

Precision-tooled for 3.1 data integrity, this 3.1 Type-C connector features single-layer board-mount construction with standard cable exit orientation. The standard contact...

Request a Quote →

3.1 Type-C interface10Gbps Gen 2 transfer

Single-layer PCB designSingle-row straight pin layout

90° exit angleStandard cable exit

10Gbps SuperSpeed+ capableCompact board footprint

Technical Specifications

USB Version	USB 3.1
Connector Type	USB Type-C
Mount Type	Board-Mount
Layers	Single-Layer
Orientation	90 Degree
Pin Configuration	Standard
Rated Current	1.8A (0.25A for other contacts)
Rated Voltage	30V DC
Contact Resistance	30mΩ
Insulation Resistance	100MΩ
Withstand Voltage	100V
Contact Material	U2 contacts: Phosphor Bronze, half gold-tin plated; U3 contacts: Brass, half gold-tin plated
Insulator Material	High-Temperature Plastic, UL94-V0
Shell Material	SUS, nickel plated
Data Speed	10Gbps
Operating Temperature	-55°C to +85°C
Certifications	CE, RoHS, REACH

Key Features

USB 3.1 Type-C connector supporting standard 3.1 data protocols
Single-layer PCB design with 90° cable exit for flexible board integration
Standard contact configuration for full USB signaling compatibility
Stackable contact geometry optimized for specific mating and retention requirements
Robust mechanical structure for reliable mating-cycle durability
Suitable for high-vibration installations including marine and rail

Applications

Consumer Electronics
Computer Peripherals
Industrial Control Systems
Communication Devices
Automotive Infotainment
Medical Devices
IoT Hardware

Product Drawing

Precision-tooled for 3.1 data integrity, this 3.1 Type-C connector features single-layer board-mount construction with standard cable exit orientation. The standard contact configuration supports full USB 3.1 signaling requirements for data and power delivery. Suitable for consumer electronics, industrial controls, and embedded computing platforms requiring USB interconnect. Each unit ships ready for board-mount installation with industry-standard pin pitch for drop-in compatibility with mainstream PCB assembly processes.
