Stackable Type-C USB 3.1 Triple-Layer Connector – C071317
USB 3.110GbpsBoard-Mount
Optimized for compact PCB footprint designs, this 3.1 Type-C connector features triple-layer board-mount construction with standard cable exit orientation. The standard contact...
3.1 Type-C interface10Gbps SuperSpeed+ rate
Triple-layer PCB designTriple-stack pin design
None° exit angleStandard cable exit
USB 3.1 Gen 2 certifiedStandardized 0.1" pin pitch
Technical Specifications
| USB Version | USB 3.1 |
| Connector Type | USB Type-C |
| Mount Type | Board-Mount |
| Layers | Triple-Layer |
| Orientation | 90 Degree |
| Pin Configuration | Standard |
| Rated Current | 4A |
| Rated Voltage | 30V DC |
| Data Speed | 10Gbps |
| Operating Temperature | -40C to +85C |
| Certifications | CE, RoHS, REACH |
Key Features
- USB 3.1 Type-C connector supporting standard 3.1 data protocols
- Triple-layer PCB design with None° cable exit for flexible board integration
- Standard contact configuration for full USB signaling compatibility
- Stackable contact geometry optimized for specific mating and retention requirements
- Compatible with hand-soldering and reflow soldering processes for flexible production
- Compatible with gaming peripherals, keyboards, mice, and high-speed I/O
Applications
- Consumer Electronics
- Computer Peripherals
- Industrial Control Systems
- Communication Devices
- Automotive Infotainment
- Medical Devices
- IoT Hardware
Product Drawing
Optimized for compact PCB footprint designs, this 3.1 Type-C connector features triple-layer board-mount construction with standard cable exit orientation. The standard contact configuration supports full USB 3.1 signaling requirements for data and power delivery. Compatible with hand-soldering, wave-soldering, and reflow-soldering processes for flexible production deployment. Each unit ships ready for board-mount installation with industry-standard pin pitch for drop-in compatibility with mainstream PCB assembly processes.
