TYPE-C male connector TYPE-C plug TYPE-C socket – GSC-TYP-0159

TYPE-C male connector TYPE-C plug TYPE-C socket – GSC-TYP-0159

Type C24 PinSMT
Tags:
#24 Pin#PCB#SMT#USB Connector#USB Type-C
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0159 is a type C 24-contact connector, 8.8×15.5×2.9 mm, universal type, 24-pin (surface-mount), Type-C male connector. GSCONN part GSC-TYP-0159.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
24 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeUniversal / 24P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 8.8×15.5×2.9 mm
  • universal type
  • 24-pin (surface-mount)
  • Type-C male connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C male connector TYPE-C plug TYPE-C socket – GSC-TYP-0159 drawing

GSC-TYP-0159 is a type C 24-contact connector, 8.8×15.5×2.9 mm, universal type, 24-pin (surface-mount), Type-C male connector.

Series TYPE-C JACKES
Type Universal / 24P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N
