TYPE-C receptacle TYPE-C female connector Through-hole TYPE-C interface – GSC-TYP-0140

TYPE-C receptacle TYPE-C female connector Through-hole TYPE-C interface – GSC-TYP-0140

Type C16 PinSMT
Tags:
#16 Pin#PCB#Receptacle#SMT#USB Connector#USB Type-C
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0140 is a type C 16-contact connector, 8.94×6.5×3.16 mm, 0.8 mm thick board, 16-pin (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0140.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
Type0.8 mm thick board / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • 8.94×6.5×3.16 mm
  • 0.8 mm thick board
  • 16-pin (surface-mount type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C receptacle TYPE-C female connector Through-hole TYPE-C interface – GSC-TYP-0140 drawing

GSC-TYP-0140 is a type C 16-contact connector, 8.94×6.5×3.16 mm, 0.8 mm thick board, 16-pin (surface-mount type), Type-C connector.

Series TYPE-C JACKES
Type 0.8 mm thick board / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf
