TYPE-C Socket 16P Waterproof TYPE-C Female Connector Board-Mounted Type Interface – GSC-TYP-0199

TYPE-C Socket 16P Waterproof TYPE-C Female Connector Board-Mounted Type Interface – GSC-TYP-0199

Type C16 PinSMTWaterproof
Tags:
#16 Pin#PCB#Receptacle#SMT#USB Connector#USB Type-C#Waterproof
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0199 is a type C 16-contact connector, waterproof IP67 16P (Surface-Mount) Type-C Connector. GSCONN part GSC-TYP-0199.

Request a Quote → Download Datasheet
IP67Rated ingress protection
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeWaterproof IP67 / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • Waterproof IP67 16P (Surface-Mount) Type-C Connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket 16P Waterproof TYPE-C Female Connector Board-Mounted Type Interface – GSC-TYP-0199 drawing

GSC-TYP-0199 is a type C 16-contact connector, waterproof IP67 16P (Surface-Mount) Type-C Connector.

Series TYPE-C JACKES
Type Waterproof IP67 / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf

Downloads

Technical DrawingPDF · 180 KB
