GSC-TYP-0147 is a type C 16-contact connector, 9.7×4.59×6 mm, waterproof IPX5, 16-pin (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0147.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeWaterproof rating IPX5 / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • 9.7×4.59×6 mm
  • waterproof IPX5
  • 16-pin (surface-mount type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket 16P Waterproof TYPE-C Female Connector Vertical TYPE-C Interface – GSC-TYP-0147 drawing

GSC-TYP-0147 is a type C 16-contact connector, 9.7×4.59×6 mm, waterproof IPX5, 16-pin (surface-mount type), Type-C connector.

Series TYPE-C JACKES
Type Waterproof rating IPX5 / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf
