TYPE-C Socket Horizontal TYPE-C Female Connector 24-Pin Interface – GSC-TYP-0101
Type C24 PinSMTRight Angle
GSC-TYP-0101 is a type C 24-contact connector, horizontal 24P, long body, 12.4 mm (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0101.
Surface MountSMT termination
10,000 CyclesRated mating life
24 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Horizontal / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- Horizontal 24P
- long body
- 12.4 mm (surface-mount type)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0101 is a type C 24-contact connector, horizontal 24P, long body, 12.4 mm (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Horizontal / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
