TYPE-C Socket Raised TYPE-C Female Connector 16-Pin Interface – GSC-TYP-0095

TYPE-C Socket Raised TYPE-C Female Connector 16-Pin Interface – GSC-TYP-0095

Type C16 PinSMTRight Angle
Tags:
#16 Pin#PCB#Receptacle#Right Angle#SMT#USB Connector#USB Type-C
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0095 is a type C 16-contact connector, horizontal 16P, raised by 7 mm (surface-mount type), with a Type-C connector. GSCONN part GSC-TYP-0095.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
Type7mm heightening / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.8–2.0 kgf

Key Features

  • Horizontal 16P
  • raised by 7 mm (surface-mount type)
  • with a Type‑C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket Raised TYPE-C Female Connector 16-Pin Interface – GSC-TYP-0095 drawing

GSC-TYP-0095 is a type C 16-contact connector, horizontal 16P, raised by 7 mm (surface-mount type), with a Type-C connector.

Series TYPE-C JACKES
Type 7mm heightening / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.8–2.0 kgf

Downloads

Technical DrawingPDF · 123 KB
