TYPE-C Socket Through-Hole TYPE-C Female Connector TYPE-C Interface – GSC-TYP-0179

TYPE-C Socket Through-Hole TYPE-C Female Connector TYPE-C Interface – GSC-TYP-0179

Type C6 PinSMTWaterproof
Tags:
#6 Pin#PCB#Receptacle#SMT#USB Connector#USB Type-C#Waterproof
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0179 is a type C 6-contact connector, 10.54×4.1×8.15 mm, flush-mount type, waterproof to IPX7, 6P (surface-mount), Type-C connector. GSCONN part GSC-TYP-0179.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeRecessed Plate Waterproof Type / 6P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 10.54×4.1×8.15 mm
  • flush-mount type
  • waterproof to IPX7
  • 6P (surface-mount)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket Through-Hole TYPE-C Female Connector TYPE-C Interface – GSC-TYP-0179 drawing

GSC-TYP-0179 is a type C 6-contact connector, 10.54×4.1×8.15 mm, flush-mount type, waterproof to IPX7, 6P (surface-mount), Type-C connector.

Series TYPE-C JACKES
Type Recessed Plate Waterproof Type / 6P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 67 KB
